High-speed designs use digital components with very fast edge rates in their output signals which can be subjected to significant distortion and degradation creating high bit-error-rates and lower data throughput. Insertion and reflection losses, crosstalk and impedance mismatch, are all factors, amongst others, influencing the integrity of a transmitted signal.

Empower’s E-CAP silicon capacitors provide wide bandwidth low impedance highly stable decoupling capacitors capable of being placed close and even integrated into an SoC substrate.

Empower Semiconductor is developing power management solutions enabling full unrestricted speed and performance of the latest xPUs.

High power density
High bandwidth conversion
Low power distribution losses
Vertical Power

The ability to process data and perform complex calculations at high speeds has been intensified in recent years by leaps in technologies such as artificial intelligence, 3-D imaging and autonomous driving. These technologies have exacerbated the need for faster and more complex processors and architectures.

Equipment designed to operate within a high magnetic field environment can experience power failures or abnormal operating conditions due to the force the magnetic field imposes on ferromagnetic material-based electronics.

Moreover, magnetic resonance imaging (MRI) devices can record false or distorted images due to the inferences from such electronics. Empower’s IVRs regulators use non-ferromagnetic air-core inductors ideal for operating in harsh magnetic environments.

Data being communicated and processed around the globe is rapidly growing, driving the need for a new generation of faster data processing components and elements in data centers and datacom equipment.

Empower Semiconductor offers novel fully integrated power management solutions that both increase performance and solve the power density challenge of space-constrained data-intensive applications.

System-on-Modules (SOMs) and Computer-on-Modules (CoMs) provide all components of an embedded processing system (processors, communication interfaces, memory blocks, power management, etc.) on a single production-ready printed circuit board (PCB). This modular approach makes them ideal for embedding into a variety of end systems and applications.Empower’s IVRs provide high-density configurable multi-rails regulators enabling rapid and flexible prototyping.

Chiplet architectures are rapidly gaining popularity over monolithic designs in developing complex SoCs. While providing increased performance, design flexibility and upgradability, they do, however, require more complex power management and PCB routing.

Empower’s IVRs can be integrated as an additional chiplet into an SoC increasing the power delivery efficiency and simplifying PCB routing.

World’s Smallest and Fastest Voltage Regulators

Empower IVR

Q

Traditional power solutions require dozens of discrete components with big footprints, complex designs and deliver power inefficiently with poor response times and inaccuracies.

Empower’s patented IVR technology eliminates dozens of discrete components by using a single IC with greater efficiency and 10x reduction in PCB area. The result is power delivery with unprecedented simplicity, speed, accuracy, and NO discrete components!

Part Number	Description	Input Voltage	VR Regulated Outputs	VR1 lout [A]	VR2 lout [A]	VR3 lout [A]	VR4 lout [A]	Vout Min [V]	Vout Max [V]	Package Type	Package Size (L x W) [mm]	Package Thickness [mm]	Product Brief	Buy/Inquire
EP7010C	Single Output 10A IVR	1.8V	1	10	---	---		0.50	1.20	FcCSP	5 x 5	0.75
EP7010B	Single Output 10A IVR on Interposer	1.8V	1	10	---	---		0.50	1.20	LGA	8 x 10	2.45
EP7015C	Single Output 5A IVR	1.8V	1	5	---	---		0.50	1.20	FcCSP	5 x 5	0.75
EP7024C	Dual Output 6A IVR	1.8V	2	3	3	---		0.50	1.20	FcCSP	5 x 5	0.75
EP7027C	Dual Output 10A IVR	1.8V	2	8	2			0.50	1.20	FcCSP	5 x 5	0.75
EP7027B	Dual Output 10A IVR on Interposer	1.8V	2	8	2			0.50	1.20	LGA	8 x 10	2.45
EP7028C	Dual Output 10A IVR	1.8V	2	6	4			0.50	1.20	FcCSP	5 x 5	0.75
EP7029C	Dual Output 10A IVR	1.8V	2	5	5	---		0.50	1.20	FcCSP	5 x 5	0.75
EP7029B	Dual Output 10A IVR on Interposer	1.8V	2	5	5			0.50	1.20	LGA	8 x 10	2.45
EP7032C	Triple Output 6A IVR	1.8V	3	2	2	2		0.50	1.20	FcCSP	5 x 5	0.75
EP7037C	Triple Output 10A IVR	1.8V	3	6	2	2		0.50	1.20	FcCSP	5 x 5	0.75
EP7037B	Triple Output 10A IVR on Interposer	1.8V	3	6	2	2		0.50	1.20	LGA	8 x 10	2.45
EP7038C	Triple Output 10A IVR	1.8V	3	4	2	4		0.50	1.20	FcCSP	5 x 5	0.75
EP7038B	Triple Output 10A IVR on Interposer	1.8V	3	4	2	4		0.50	1.20	LGA	8 x 10	2.45
EP7112	Single Output 12A IVR	3.3V	1	12	---	---	---	0.50	2.50	FcCSP	7.0 x 5.0	0.70
EP7122	Single Output 12A IVR	3.3V	2	9	3	---	---	0.50	2.50	FcCSP	7.0 x 5.0	0.70
EP7123	Dual Output 12A IVR	3.3V	2	6	6	---	---	0.50	2.50	FcCSP	7.0 x 5.0	0.70
EP7133	Triple Output 9A IVR	3.3V	3	3	3	3	---	0.50	2.50	FcCSP	7.0 x 5.0	0.70
EP7136	Triple Output 12A IVR	3.3V	3	6	3	3	---	0.50	2.50	FcCSP	7.0 x 5.0	0.70
EP7139	Triple Output 12A IVR	3.3V	3	9	1.5	1.5	---	0.50	2.50	FcCSP	7.0 x 5.0	0.70
EP7142	Quad Output 6A IVR	3.3V	4	1.5	1.5	1.5	1.5	0.50	2.50	FcCSP	7.0 x 5.0	0.70
EP7143	Quad Output 12A IVR	3.3V	4	3	3	3	3	0.50	2.50	FcCSP	7.0 x 5.0	0.70
EP7144	Quad Output 12A IVR	3.3V	4	4.5	4.5	1.5	1.5	0.50	2.50	FcCSP	7.0 x 5.0	0.70
